75-ton Cleveland mechanical horn-type punch press with air clutch and brake, made in the USA.

This heavy-duty press was acquired by us in 1991 at the bankruptcy of Industrial Metals & Machinery, and moved from their warehouse to ours at that time. As this is a rare beast, vital for work on cylindrical or tubular metal, or on small items requiring a large force, we guess they had it for about 5-10 years. All this to say, this press has not been wearing down for at least 30-35 years! It was always in good condition. It should have many more decades of long and happy use with you, punching away on your horning and punching applications in your shop or plant.

Specifications

• Manufacturer: "Cleveland" (USA)
• Model: 9H
• S/N: 10293-2
• Capacity: 75 tons
• Ram area: 14" x 14"
• Stroke: 4"
• Strokes/min: 45 SPM
• Slide shut height: 9" over 10" bar installed
• Slide adjustment: 3"
• Throat: 15"
• Horn diameter: 10" (6")
• Electrics: 220/440V 3 ph, 60 Cy.

Equipped with

• Air clutch & air brake
• Installed horn bar, 10" dia. in main frame, reduced to 6" dia. under slide
• Central automatic lubrication
• Filter-reg-lube + air reservoir
• 1-shot air lubricator

Notes

We had this machine almost sold to a company manufacturing pole-line transformers, as seen everywhere in North America, to punch and/or shape the tubular body. Unfortunately, their needs changed.

This press is worth every penny we're asking. What more could you ask? This machine was made proudly by Americans for Americans, with all reliable USA-sourced materials! We ship it to you, in the USA, duty-free.

Price: FOB warehouse, loaded on truck. All shipping-related costs are extra.

Payment: you may send us a certified check or a bank check (bank draft) on any standard US or Canadian bank or credit union. On receipt, we'll ship as soon as practical. We'll just as soon accept your personal or company check, sent by tracked mail or courier: we'll deposit it quickly and ship as soon as the payment clears.

NB: it is the buyer's entire responsibility to make sure that this press and its operation fully conform with all national, state and local laws regarding workplace and worker safety.

We're happy to send you any more technical specs, photos, measurements, etc. Call us toll-free: 1-888-459-4025.

We can take care of all shipping logistics if you send us your contact info and shipping address, or you can use your own trucker. Logistics problems? No problem, just call us for a solution. We've shipped around the world and across the street, from basements to railroad locomotive and airplane plants.

We have economical direct carrier quotes from us to your door, via approved, certified load brokers. Our logistics services make cross-border paperwork a seamless process for you.
